Продукт No.350493
Дънна платка ASROCK B760M STEEL LEGEND WIFI, LGA1700, 4xDDR4, 4800MHz, Micro ATXна ниска цена с бърза доставка

Дънна платка ASROCK B760M STEEL LEGEND WIFI, LGA1700, 4xDDR4, 4800MHz, Micro ATX

Продукт № 350493
Категория: Дънни платки
Производител:
Модел:
90-MXBL70-A0UAYZ
Чипсет:Intel B760
Брой RAM слотове:4 бр.
Поддържана памет:DDR5
Процесорен слот:LGA1700
Гаранция:
36 месеца
Наличност:ДА
На склад в: София

353.90 ЛВ
В кошницатa има:
−
0
 бр.
+

ASROCK B760M STEEL LEGEND WIFI, LGA1700, 4xDDR4, 4800MHz, Micro ATX


Графика:
  • - Intel® Xe Graphics Architecture (Gen 12); - 1 x eDP 1.4
  • supports max. resolution up to Full HD 60Hz; - 1 x HDMI 2.1 TMDS Compatible
  • supports HDCP 2.3 and max. resolution up to 4K 60Hz; - 1 x DisplayPort 1.4 with DSC (compressed)
  • supports HDCP 2.3 and max. resolution up to 8K 60Hz / 5K 120Hz
CPU's supported:- Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700); - Supports Intel® Hybrid Technology; - Supports Intel® Turbo Boost Max 3.0 Technology; - Supports Intel® Thermal Velocity Boost (TVB); - Supports Intel® Adaptive Boost Technology (ABT)
Chipset:- Intel® B760
Слотове:
  • CPU: - 1 x PCIe 5.0 x16 Slot (PCIE1)
  • supports x16 mode*; Chipset: - 1 x PCIe 4.0 x1 Slot (PCIE2)*; - 1 x M.2 Socket (Key E)
  • supports type 2230 WiFi/BT PCIe WiFi module and Intel® CNVio/CNVio2 (Integrated WiFi/BT); - 15μ Gold Contact in VGA PCIe Slot (PCIE1)
Storage:
  • CPU: - 1 x Hyper M.2 Socket (M2_1
  • Key M)
  • supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*; Chipset: - 1 x Hyper M.2 Socket (M2_2
  • Key M)
  • supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*; - 1 x Hyper M.2 Socket (M2_3
  • Key M)
  • supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode*; - 4 x SATA3 6.0 Gb/s Connectors
Тип памет:
  • - Dual Channel DDR5 Memory Technology; - 4 x DDR5 DIMM Slots; - Supports DDR5 non-ECC
  • un-buffered memory up to 7200+(OC)*; - Max. capacity of system memory: 128GB; - Supports Intel® Extreme Memory Profile (XMP) 3.0
I/O:- 2 x Antenna Ports; - 1 x PS/2 Mouse/Keyboard Port; - 1 x HDMI Port; - 1 x DisplayPort 1.4; - 1 x USB 3.2 Gen2 Type-A Port (10 Gb/s); - 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s); - 4 x USB 3.2 Gen1 Ports; - 2 x USB 2.0 Ports; - 1 x RJ-45 LAN Port; - HD Audio Jacks: Line in / Front Speaker / Microphone
Connectors:- 1 x eDP Signal Connector; - 1 x SPI TPM Header; - 1 x Chassis Intrusion and Speaker Header; - 1 x RGB LED Header*; - 3 x Addressable LED Headers**; - 1 x CPU Fan Connector (4-pin)***; - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)****; - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)*****; - 1 x 24 pin ATX Power Connector (Hi-Density Power Connector); - 2 x 8 pin 12V Power Connectors (Hi-Density Power Connector); - 1 x Front Panel Audio Connector; - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports); - 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports); - 1 x Front Panel Type C USB 3.2 Gen2 Header (10 Gb/s)
Audio:- 7.1 CH HD Audio (Realtek ALC897 Audio Codec); - Nahimic Audio
LAN:
  • - 2.5 Gigabit LAN 10/100/1000/2500 Mb/s; - Dragon RTL8125BG; - Supports Dragon 2.5G LAN Software; - Smart Auto Adjust Bandwidth Control; - Visual User Friendly UI; - Visual Network Usage Statistics; - Optimized Default Setting for Game
  • Browser
  • and Streaming Modes; - User Customized Priority Control
BIOS:- 128Mb AMI UEFI Legal BIOS with GUI support
Form Factor:
  • - Micro ATX Form Factor: 9.6-in x 9.6-in
  • 24.4 cm x 24.4 cm; - 2oz Copper PCB
Операционна система:- Microsoft® Windows® 10 64-bit / 11 64-bit
Други:- 802.11ax Wi-Fi 6E Module; - Supports IEEE 802.11a/b/g/n/ac/ax; - Supports Dual-Band 2x2 with extended 6GHz band support*; - 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology; - Supports Bluetooth 5.3 + High speed class II; - Supports MU-MIMO
Гаранция:36 Месеца
