NVR TVT 4CH TD-3004H1-4P-B1-B 64Mbps, 1xHDD, POE

NVR TVT 4CH TD-3004H1-4P-B1-B 64Mbps, 1xHDD, POE

Features

Support 4/8 CH 6MP/5MP/4MP/3MP/1080P/ 960P/720P/960H/DI/CIF IP video input

H.265S/H.265+/H.265/H.264 coding

Intuitive and user-friendly Graphic User Interface (GUI), Windows style operation by mouse

Multi-type recording: manual / timed / motion / sensor / POS / AI recording

Playback: 4 /8CH simultaneous playback

Search: time slice, time, event, tag, smart search

Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, crowd density, etc.

Support POS information overlay on live view and playback

Express and flexible backup via USB, network and so on

Support preview, record, playback, backup and remote access

DHCP, DDNS, PPPoE network protocol

4/8 PoE network ports; IPCs can be directly connected to NVR; PoE power supply supported

Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration

Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device

Authorization management, log view and device status view

1080P HD output, true high-resolution display

Support NAT function and QR Code scanning by mobile phones

Powerful mobile surveillance by smart phones with iOS and Android OS

Specification

Model		TD-3004H1-4P-B1-B	TD-3008H1-8P-B1-B
System	OS	Embedded Linux
Video	Network Input	4 CH IPC input	8CH IPC input
	Network Input Resolution	6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF
	Output	HDMI × 1: 1920 × 1080 / 1280 × 1024/ 1024 × 768 VGA: 1920 × 1080 / 1280 × 1024/ 1024 × 768 HDMI and VGA output the same video source
	Compression	H.265S / H.265+ /H.265 /H.264
	Multi-screen Display	1月4日	1 / 4 / 6 / 8 / 9
Audio	Network Input	4 CH IPC audio input	8 CH IPC audio input
	Local Input	No
	Local Output	No (HDMI supports the audio output)
	Compression	G.711(U/A)
Record	Resolution	6MP/5MP/4MP/3MP/1080P/960P/720P/D1/CIF
	Frame Rate	30fps/25fps (NTSC/PAL)
Playback	Simultaneous Playback	Max. 4 CH	Max. 8 CH
	Search	Time slice / time / event / tag /smart search
	Smart Search	Highlighted color to display the camera record in a certain period of time, different colors refer to different record events
	Function	Play, pause, FF, FB, digital zoom, etc.
Decoding Capability	Live View/ Playback	1CH 6MP; 4CH 1080P
Alarm	Type	Manual, sensor, motion, exception, smart events, etc.
	Input	No
	Output	No
	Triggering	Record, snapshot, buzzer, preset, e-mail, etc.
Network	Interface	RJ 45 100Mbps × 1
	Protocol	TCP/ IP, HTTP, HTTPS, 802.1, DHCP, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP,IPv6, IPv4, UDP, WebSocket, PPPoE, SNMP, IGMP, ONVIF, etc.
	Incoming/ Outgoing Bandwidth	40/64 (Mbps)	64/64 (Mbps)
		*When the AI function of the IPC is enabled, the actual incoming bandwidth (max.bitrate) is more than the set value in the NVR.
	Client Connection	Max. 64 users' access
LPR	Plate Detection (AI by IPC)	Yes
Mobile Device	OS	iOS, Android
Storage	HDD Interface	SATA3.0 × 1, max 10T
Backup	Local Backup	USB flash drive
	Network Backup	Yes
Port	USB	USB 2.0 × 2
	Remote Controller	No
PoE	PoE Ports	100M RJ45 × 4	100M RJ45 × 8
	Standards	IEEE802.3AF/AT
	Output Power	≤ 40W	≤72W
Others	Power Supply	DC 48V/1.25A
	Consumption	≤ 5W (without HDD, and PoE off)
	Dimensions (mm)	255 × 222 × 42 (W × D × H)
	Working Environment	-10 ～ 50 ℃，10% ～ 90% humidity
	Certificate	CE, FCC
	Environmental Protection	Complies with Directive EU RoHS, REACH and WEEE
