| Категория: | несортирани |
| Производител: | |
| Гаранция: | 24 месеца |
На склад в: София
699.00 ЛВ
NVR TVT 32CH TD-3332H2-A2 256Mbps, 2xHDD, AI
Features
Support 16/32CH 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF IPC Input
H.265S/H.265+/H.265/H.264
Intuitive and user-friendly Graphic User Interface (GUI), Windows style operation by mouse
Multi-type recording: manual / timed / motion / sensor / POS / AI recording
Playback: 16 CH simultaneous playback
Search: time slice, time, event, tag and smart search
Support face detection and comparison
Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.
Support license plate recognition
Support POS information overlay on live view and playback
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high-resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR Code scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Android OS
Specification
Model TD-3316H2-A2 TD-3332H2-A2 System OS Embedded Linux Video Compression H.265S/H.265+/H.265/H.264 IP Video Input 16CH IPC input 32CH IPC input Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF Network Bandwidth 160Mbps/160Mbps (incoming/outgoing) 192Mbps/192Mbps (incoming/outgoing) Output HDMI1: 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768 HDMI2: 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA ×1: 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA and HDMI1 output the same video source Audio Network Input 16 CH IPC audio input 32 CH IPC audio input 2-way Audio RCA × 1 Local Output RCA × 1 Compression G.711(U/A) Record Record Stream Dual stream recording Resolution 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF Frame Rate NTSC: 30fps; PAL: 25fps Playback Simultaneous Playback Max 16CH Search Time slice / time / event / tag / smart search Smart Search Highlighted color to display the camera record in a certain period of time, different colors refer to different record events Function Play, pause, FF, FB, digital zoom, etc. Decoding Capability Live View/ Playback 1CH 12MP/4CH 1080P Multi-Screen Display Mode Mode Dual output mode (default mode): supports HDMI2 output, but doesn’t support AI by device AI mode: HDMI2 output and 12MP video input (live view/playback) are unavailable, but 8MP video input supports Dual Output Mode 16CH (HDMI1) +9CH (HDMI2) 32CH (HDMI1) +4CH (HDMI2) AI Mode 16CH(HDMI1) 24CH (HDMI1) Alarm Mode Manual, sensor, motion, exception, smart events, etc. Input 8 CH local alarm input Output 4 CH Triggering Record, snap, preset, e-mail, etc. Face Face Detection Performance (AI by IPC) 16CH 32CH Face Detection Performance (AI by Device) 2 CH (2MP) Face Match Performance 6 CH Comparison Capability 18 pictures / second Face Picture Database 32 libraries 10000 Face Pictures Face Picture Search Search by picture is supported Database Management Add, modify, delete and search face pictures Face Picture Adding Add face pictures through APP, WEB and external import Face Picture Comparison Support allow list, block list and stranger match alarm Track Track display on a map Statistical Graph of Information Bar graph Statistical Mode of Information Statistics by day, week, month, quarter as well as customized time period Video Structure Analysis Human/Vehicle Classification Yes Other Functions Fisheye Supports fisheye dewarping via Web Client and mobile APP Plate Recognition Yes Network Interface RJ 45 1000 Mbps × 2 Protocol TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, SNMP, ONVIF, etc. Client Connection Max. 10 users access Max. 20 users' access Mobile Device OS iOS, Android Storage HDD Interface SATA × 2, max 10T for each HDD Backup Local Backup U disk, USB mobile HDD Network Backup Yes External Interface RS 485 Yes (full-duplex), connect to PTZ or keyboard USB USB 3.0 × 1; USB 2.0 × 2 Remote Controller Optional Others Power Supply DC12V/4A Consumption ≤ 20W (without HDD) Certificate CE, FCC Environmental Protection Complies with Directive EU RoHS, REACH and WEEE Dimensions(mm) 380 × 268 × 45 (W × D × H) Working Environment <
* Изображенията на продуктите в сайта са примерни и може да имат разлики с действителните продукти. Ако забележите такава, моля пишете ни на адрес store@bestpc.bg.
* Ние се стремим да дадем най-добрата цена. Ако друга фирма Ви предлага по-изгодна оферта от нашата - обадете ни се и ще Ви направим дори още по-добро предложение.
Support 16/32CH 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF IPC Input
H.265S/H.265+/H.265/H.264
Intuitive and user-friendly Graphic User Interface (GUI), Windows style operation by mouse
Multi-type recording: manual / timed / motion / sensor / POS / AI recording
Playback: 16 CH simultaneous playback
Search: time slice, time, event, tag and smart search
Support face detection and comparison
Support multiple VCA (Video Content Analytics) events, such as object abandoned/missing, region intrusion, tripwire, video exception, etc.
Support license plate recognition
Support POS information overlay on live view and playback
Pentaplex: preview, record, playback, backup and remote access
DHCP, DDNS, PPPoE network protocol
Compatible with third-party IPCs, such as ONVIF, Hikvision, etc.
Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration
Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
Multi-user online simultaneously
Authorization management, log view and device status view
4K output, true high-resolution display
Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
Support NAT function and QR Code scanning by mobile phones
Powerful mobile surveillance by smart phones with iOS and Android OS
Specification
| Model | TD-3316H2-A2 | TD-3332H2-A2 | |
| System | OS | Embedded Linux | |
| Video | Compression | H.265S/H.265+/H.265/H.264 | |
| IP Video Input | 16CH IPC input | 32CH IPC input | |
| Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | ||
| Network Bandwidth | 160Mbps/160Mbps (incoming/outgoing) | 192Mbps/192Mbps (incoming/outgoing) | |
| Output | HDMI1: 3840 × 2160/1920 × 1080 / 1280 × 1024 / 1024 × 768 | ||
| HDMI2: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| VGA ×1: 1920 × 1080 / 1280 × 1024 / 1024 × 768 | |||
| VGA and HDMI1 output the same video source | |||
| Audio | Network Input | 16 CH IPC audio input | 32 CH IPC audio input |
| 2-way Audio | RCA × 1 | ||
| Local Output | RCA × 1 | ||
| Compression | G.711(U/A) | ||
| Record | Record Stream | Dual stream recording | |
| Resolution | 12MP/8MP/6MP/5MP/4MP/3MP/1080P/1280×1024/960P/720P/960H/D1/CIF | ||
| Frame Rate | NTSC: 30fps; PAL: 25fps | ||
| Playback | Simultaneous Playback | Max 16CH | |
| Search | Time slice / time / event / tag / smart search | ||
| Smart Search | Highlighted color to display the camera record in a certain period of time, different colors refer to different record events | ||
| Function | Play, pause, FF, FB, digital zoom, etc. | ||
| Decoding Capability | Live View/ Playback | 1CH 12MP/4CH 1080P | |
| Multi-Screen Display Mode | Mode | Dual output mode (default mode): supports HDMI2 output, but doesn’t support AI by device | |
| AI mode: HDMI2 output and 12MP video input (live view/playback) are unavailable, but 8MP video input supports | |||
| Dual Output Mode | 16CH (HDMI1) +9CH (HDMI2) | 32CH (HDMI1) +4CH (HDMI2) | |
| AI Mode | 16CH(HDMI1) | 24CH (HDMI1) | |
| Alarm | Mode | Manual, sensor, motion, exception, smart events, etc. | |
| Input | 8 CH local alarm input | ||
| Output | 4 CH | ||
| Triggering | Record, snap, preset, e-mail, etc. | ||
| Face | Face Detection Performance (AI by IPC) | 16CH | 32CH |
| Face Detection Performance (AI by Device) | 2 CH (2MP) | ||
| Face Match Performance | 6 CH | ||
| Comparison Capability | 18 pictures / second | ||
| Face Picture Database | 32 libraries | ||
| 10000 Face Pictures | |||
| Face Picture Search | Search by picture is supported | ||
| Database Management | Add, modify, delete and search face pictures | ||
| Face Picture Adding | Add face pictures through APP, WEB and external import | ||
| Face Picture Comparison | Support allow list, block list and stranger match alarm | ||
| Track | Track display on a map | ||
| Statistical Graph of Information | Bar graph | ||
| Statistical Mode of Information | Statistics by day, week, month, quarter as well as customized time period | ||
| Video Structure Analysis | Human/Vehicle Classification | Yes | |
| Other Functions | Fisheye | Supports fisheye dewarping via Web Client and mobile APP | |
| Plate Recognition | Yes | ||
| Network | Interface | RJ 45 1000 Mbps × 2 | |
| Protocol | TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, NTP, SMTP, HTTP, HTTPs, 802.1x, RTSP, SNMP, ONVIF, etc. | ||
| Client Connection | Max. 10 users access | Max. 20 users' access | |
| Mobile Device | OS | iOS, Android | |
| Storage | HDD Interface | SATA × 2, max 10T for each HDD | |
| Backup | Local Backup | U disk, USB mobile HDD | |
| Network Backup | Yes | ||
| External Interface | RS 485 | Yes (full-duplex), connect to PTZ or keyboard | |
| USB | USB 3.0 × 1; USB 2.0 × 2 | ||
| Remote Controller | Optional | ||
| Others | Power Supply | DC12V/4A | |
| Consumption | ≤ 20W (without HDD) | ||
| Certificate | CE, FCC | ||
| Environmental Protection | Complies with Directive EU RoHS, REACH and WEEE | ||
| Dimensions(mm) | 380 × 268 × 45 (W × D × H) | ||
| Working Environment | <|||
