DVR TVT 16CH Hybrid TD-2716NE-HC-H, +2CH IPC

DVR TVT 16CH Hybrid TD-2716NE-HC-H, +2CH IPC

Features

Supports 16 CH TVI / AHD /CVI  5MP / 4MP / 1080P / 720P / WD1 video input Supports 8 CH 5MP / 4MP / 3MP / 1080P / 960P / 720P IP video input

8CH analog video input can be switched to 8CH IP video input

Standard H.265 high profile compression format to get high-quality video at much lower bit rate

Intuitive and user-friendly Graphics User Interface (GUI), window style operation by mouse

Multi-mode recording: manual / timed / motion /sensor / AI recording

Playback: 16 CH simultaneously playback

Search: time slice, time, event, tag and smart search

Express and flexible backup via USB, network and so on

Pentaplex: preview, record, playback, backup and remote access

DHCP, DDNS, PPPoE network protocol

Remote control via Web Client or CMS: preview, playback, backup, PTZ and configuration

Support remote network transmission and remote surveillance with mobile device

Authorization management, log review and device status review

1080P output, true high-resolution display

Supports PTZ preset and auto cruise, up to 255 presets and 8 cruises

Supports NAT function and QR Code scanning by mobile phones

Powerful mobile surveillance by smart phones with iOS and Android OS

Specification

Model		TD-2716NE-HC-H
System	OS	Embedded Linux
Video	Analog Video Input	BNC × 16
		BNC interface (1.0Vp-p; 75Ω)
		TVI/AHD/CVI: 5MP@20fps; 4MP/1080P/720P/WD1@30fps (live)
	IP Video Input	8CH (up to 16CH)
		Up to 5MP@30fps
	Total Input	24CH
	Output	HDMI × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 768 VGA × 1: 1920 × 1080 / 1280 × 1024 / 1024 × 768
		BNC × 1: CVBS (used as the main or spot output)
	Compression	H.264/H.265/H.265+
	Multi-screen Display	1/4/6/8/9/13/16/25
Audio	Input	RCA × 8
	Output	RCA × 1 (linear, 600Ω)
	Two-way audio	Take up channel one audio input
	Compression	G.711(U/A)
Record	Resolution	5MP Lite/4MP Lite / 1080P/1080P Lite/720P/WD1
		AnalogChannel: 5MP Lite@10fps (PAL / NTSC); 4MP Lite/1080P@12fps (PAL) / 15fps(NTSC); 1080P Lite/720P/WD1/D1@25fps (PAL) / 30fps (NTSC)
	Frame Rate	IP Channel: 25fps (PAL) / 30fps (NTSC)
	Bit Rate	32Kbps ~ 5Mbps
	Mode	Manual, timer, motion, smart event, etc.
Playback	Playback	16CH
	Search	Time slice / time / event / tag search
	Smart Search	Highlight colors to display the camera record in a certain period of time,
		different colors refer to different record events
	Function	Play, pause, FF, FB, digital zoom, etc.
Alarm	Mode	Manual, motion, exception, sensor, smart event
	Input	16CH
	Output	4CH
AI Function	Smart Motion Detection Performance	16CH
	Perimeter Protection Performance	1CH
Network	Interface	RJ 45 1000Mbps × 1
	Protocol	TCP / IP, PPPoE, DHCP, DNS, DDNS, UPnP, HTTP, HTTPs, NTP, SMTP
	Incoming Bandwidth	32Mbps (max. 64Mbps)
	Outgoing Bandwidth	96Mbps
	Client Connection	Max. 10 users' access
Mobile Device	OS	iOS, Android
Storage	HDD	SATA×2, up to 10TB per HDD; E-SATA×1
Backup	Local Backup	U disk, USB mobile HDD
	Network Backup	Yes
Port	RS 485	Yes (half-duplex), connect to PTZ or keyboard
	USB	USB 2.0 ×1; USB3.0×1
	Remote Controller	Optional
Others	Power Supply	DC12V/4A
	Consumption	≤ 15W (without HDD)
	Dimensions(mm)	380 × 268 × 45 (W × D × H)
	Working Environment	-10~50°C, 10%~90% (humidity)
	Certificate	CE, FCC
	Environmental Protection	Directive EU RoHS, WEEE, REACH
