Инструмент/Тестер Сплайсер FUJIKURA 90S+ с резачка CT-50

Сплайсер FUJIKURA 90S+ с резачка CT-50

• Active Blade rotation by motor
  The 90S+ and CT50 fiber cleaver are enabled with wireless data connectivity. This capability allows automatic cleaver
  blade rotation when the 90S+ judges the blade is worn. The 90S+ can connect to two CT50s simultaneously.
  Active Blade life management
  The 90S+ displays the remaining blade life and informs the user when a blade height changes, position changes, or new blade is required.

  Automatic Open-Close Wind protectors

  The faster automated features of the 90S+ reduce installation times. With this splicer, an operator can complete the entire splice process
  from splicing to heating without touching the 90S+ and only moving the fiber.
  Fiber retention clamp
  The fiber retention clamps support automated operations. When the sheath clamps open automatically after splicing, the fiber retention
  clamps gently hold the spliced fiber to keep it from flying out. The retention clamps release when the fiber is lifted by the operator.
  Operation time reduction

  The shape of the sheath clamp is optimized for 60mm length protection sleeves. The length from splice point to the edge of the sheath clamp is 30mm.
  Therefore, it is easy to center the protection sleeve over the splice by using your fingers to reference the splice point.
  These functions enable the 90S+ to reduce operation time by 50% over the previous model.
  Loose tube Compatibility
  The sheath clamp of the 90S+ is compatible with loose tube fiber. The Protrusion part on of the sheath clamp for loose tube fiber engages or retracts
  by simply changing the switch position with your finger.

  Tool-less Electrodes and illumination
  The 90S+ electrodes come as an “assy” including the fixing screw. You can rotate the screw by hand without tools, enabling easy electrode replacement.
  The transparent electrode covers support wider illumination of the v-groove. As the sheath clamp opens on the opposite side of the illumination lamp,
  the sheath clamp area is illuminated without shadow.


  90S+ Standard Package


  • Core Alignment Fusion Splicer 90S+ - 1 pc
  • Battery Pack* BTR-15 - 1 pc
  • AC Adapter ADC-20 - 1 pc
  • AC Power Cord ACC-14, 15, 16 17or 18 - 1 pc
  • USB Cable USB-01 - 1 pc
  • Fusion Splicer Strap ST-02 - 1 pc
  • Electrodes (spare) ELCT2-16B - 1 pair
  • Fiber Holder Set Plate SP-03 - 1 pair
  • Carrying Case CC-39 - 1 pc
  • Work Tray Left WT-09L = 1 pc
  • Work Tray Right WT-09R - 1 pc
  • Work Tray J-Plate JP-09 - 1 pc
  • Tripod Screw TS-03 - 2 pc
  • Carrying Case Strap ST-03 - 1 pc
  • Alcohol Dispenser AP-02 - 1 pc
  • Quick Reference Guide QRG-02-E - 1 pc
  • Single Fiber Stripper SS03 or SS01 - 1 pc
  • Optical Fiber Cleaver CT50 - 1 pc
  • Fiber Scrap Collector FDB-05 - 1 pc
  • Fiber Setting Plate AD-10-M24 - 1 pc
  • Case, for cleaver CC-37 - 1 pc
  • Hexagonal Wrench HEX-01 - 1 pc
