Integrated Graphics Processor-Intel® HD Graphics support: 1 x DisplayPort
supporting a maximum resolution of 4096x2304@60 Hz; * Support for DisplayPort 1.2 version and HDCP 2.3; 1 x HDMI port
supporting a maximum resolution of 4096x2160@60 Hz; * Support for HDMI 2.0 version and HDCP 2.3.
CPU's supported:
LGA1700 socket: Support for the 13th and 12th Generation Intel® Core™
Pentium® Gold and Celeron® Processors;L3 cache varies with CPU
Chipset:
Intel® B760 Express Chipset
Слотове:
CPU: 1 x PCI Express x16 slot
supporting PCIe 4.0 and running at x16 (PCIEX16); * For optimum performance
if only one PCI Express graphics card is to be installed
be sure to install it in the PCIEX16 slot.; Chipset: 2 x PCI Express x16 slots
supporting PCIe 3.0 and running at x1 (PCIEX1_1
PCIEX1_2)
Storage:
CPU: 1 x M.2 connector (Socket 3
M key
type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU); Chipset: 2 x M.2 connectors (Socket 3
M key
type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB
M2M_SB); 4 x SATA 6Gb/s connectors; RAID 0
RAID 1
RAID 5
and RAID 10 support for SATA storage devices
Тип памет:
Support for DDR5 7600(O.C.) /7400(O.C.) /7200(O.C.) /7000(O.C.) /6800(O.C.) /6600(O.C.) / 6400(O.C.) / 6200(O.C.) / 6000(O.C.) / 5800(O.C.) / 5600(O.C.) / 5400(O.C.) / 5200(O.C.) / 4800 / 4000 MT/s memory modules; 4 x DDR DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules
I/O:
1 x USB 3.2 Gen 2 Type-A port (red); 1 x USB Type-C® port
with USB 3.2 Gen 1 support; 1 x USB 3.2 Gen 1 port; 5 x USB 2.0/1.1 ports; 1 x DisplayPort; 1 x HDMI port; 1 x RJ-45 port; 6 x audio jacks
Connectors:
1 x 24-pin ATX main power connector; 1 x 8-pin ATX 12V power connector; 1 x CPU fan header; 1 x CPU fan/water cooling pump header; 3 x system fan headers; 1 x system fan/water cooling pump header; 2 x addressable LED strip headers; 2 x RGB LED strip headers; 3 x M.2 Socket 3 connectors; 4 x SATA 6Gb/s connectors; 1 x front panel header; 1 x front panel audio header; 1 x S/PDIF Out header; 1 x USB Type-C® header
with USB 3.2 Gen 2 support; 1 x USB 3.2 Gen 1 header; 2 x USB 2.0/1.1 headers; 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only); 1 x serial port header; 1 x Q-Flash Plus button; 1 x reset jumper; 1 x Clear CMOS jumper
Audio:
Realtek® Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel; Support for S/PDIF Out
LAN:
Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
BIOS:
1 x 256 Mbit flash; Use of licensed AMI UEFI BIOS; PnP 1.0a
DMI 2.7
WfM 2.0
SM BIOS 2.7
ACPI 5.0
Form Factor:
ATX Form Factor; 30.5cm x 24.4cm
Операционна система:
Support for Windows 11 64-bit; Support for Windows 10 64-bit
