- Integrated AMD Radeon™ Vega Series Graphics in Ryzen Series APU*; - DirectX 12
Pixel Shader 5.0; - Shared memory default 2GB. Max Shared memory supports up to 16GB.**; - Dual graphics output: Support HDMI and DisplayPort 1.2 ports by independent display controllers; - Supports HDMI 1.4 with max. resolution up to 4K x 2K (4096x2160) @ 24Hz / (3840x2160) @ 30Hz; - Supports DisplayPort 1.2 with max. resolution up to 4K x 2K (4096x2160) @ 60Hz; - Supports Auto Lip Sync
Deep Color (12bpc)
xvYCC and HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant HDMI monitor is required); - Supports HDCP 1.4 with HDMI 1.4 and DisplayPort 1.2 Ports; - Supports 4K Ultra HD (UHD) playback with HDMI 1.4 and DisplayPort 1.2 Ports
CPU's supported:
- Supports AMD AM4 Socket Ryzen™ 2000
3000
4000 G-Series
5000 and 5000 G-Series Desktop Processors; - Digi Power design; - 6 Power Phase design
Chipset:
- AMD Promontory B450
Слотове:
AMD Ryzen series CPUs (Vermeer
Matisse
Cezanne
Renoir
Summit Ridge and Pinnacle Ridge); - 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*; - 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode); AMD Ryzen series CPUs (Picasso
Raven Ridge); - 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use Athlon 2xxGE series APU
PCIE2 slot will run at x4 mode.); - 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode); AMD Athlon series CPUs; - 1 x PCI Express 3.0 x16 Slot (PCIE2: x4 mode)*; - 1 x PCI Express 2.0 x16 Slot (PCIE3: x4 mode); - 1 x PCI Express 2.0 x1 Slot; - Supports AMD Quad CrossFireX™ and CrossFireX™
Storage:
- 4 x SATA3 6.0 Gb/s Connectors
support RAID (RAID 0
RAID 1 and RAID 10)
NCQ
AHCI and Hot Plug*; - 1 x Ultra M.2 Socket (M2_1)
supports M Key type 2242/2260/2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s) (with Vermeer
Matisse
Cezanne
Renoir
Picasso
Summit Ridge
Raven Ridge and Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with Athlon series APU and Raven Ridge 2)**; - 1 x M.2 Socket (M2_2)
supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module
- 1 x PS/2 Mouse/Keyboard Port; - 1 x HDMI Port; - 1 x DisplayPort 1.2; - 1 x Optical SPDIF Out Port; - 2 x USB 2.0 Ports (Supports ESD Protection); - 1 x USB 3.1 Gen2 Type-A Port (10 Gb/s) (Supports ESD Protection); - 1 x USB 3.1 Gen2 Type-C Port (10 Gb/s) (Supports ESD Protection); - 4 x USB 3.1 Gen1 Ports (Supports ESD Protection); - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED); - HD Audio Jacks: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone (Gold Audio Jacks)
Connectors:
- 1 x COM Port Header; - 1 x TPM Header; - 1 x Chassis Intrusion Header; - 1 x Power LED and Speaker Header; - 1 x RGB LED Header*; - 1 x Addressable LED Header**; - 1 x AMD Fan LED Header***; - 1 x CPU Fan Connector (4-pin)****; - 1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)*****; - 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)******; - 1 x 24 pin ATX Power Connector; - 1 x 8 pin 12V Power Connector; - 1 x Front Panel Audio Connector; - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection); - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
- 128Mb AMI UEFI Legal BIOS with multilingual GUI support; - Supports "Plug and Play"; - ACPI 5.1 compliance wake up events; - Supports jumperfree; - SMBIOS 2.3 support; - DRAM Voltage multi-adjustment
