x16/x16/x8) ; 1 x PCIe 3.0/2.0 x16 (max at x4 mode) *1/1. PCIEX16_4 shares bandwidth with SATA6G_5 & STATA6G_6 when using 28-lane & 16-lane CPUs. PCIEX16_2 shares bandwidth with USB 3.1 Gen 2 front panel connector when using 16-lane CPUs. PCIEX16_2 max. at x4 mode when using 44 & 28 lane CPUs,only compatible with PCIe x1 & x4 devices,PCIEX16_4 max. at x2 mode in 44-lane & 28-lane CPUs PCIEX16_2 max. at x1 mode & PCIEX16_4 max. at x2 mode in 16-lane CPUs./; 2 x PCIe 3.0/2.0 x1 *2/2. PCIEX1_1 shares bandwidth with Wi-Fi 802.11ad. It is disabled by default.PCIEX1_2 shares bandwidth with SATA6G_7. It is disabled by default. /; 28-Lane CPU: 2 x PCIe 3.0/2.0 x16 (x16
x16/x8) ; 2 x PCIe 3.0/2.0 x16 (max at x4 mode) *1/1. PCIEX16_4 shares bandwidth with SATA6G_5 & STATA6G_6 when using 28-lane & 16-lane CPUs. PCIEX16_2 shares bandwidth with USB 3.1 Gen 2 front panel connector when using 16-lane CPUs. PCIEX16_2 max. at x4 mode when using 44 & 28 lane CPUs,only compatib
Storage:
Intel® X299 Chipset : 1 x M.2 x4 Socket 3
with M key
type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode); 1 x M.2 x4 Socket 3
with M key
type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode)*3/3. The M.2_2 socket shares bandwidth with U.2 port. Adjust BIOS settings to use U.2 device./; 7 x SATA 6Gb/s port(s)*4/4. The SATA6G_7 shares bandwidth with PCIEX1_2. SATA6G_5 & SATA6G_6 shares bandwidth with PCIEX16_4 when using 28-lane & 16-lane CPU./; 1 x U.2 port; Support Raid 0
1
5
10; Supports Intel® Smart Response Technology; Intel® Rapid Storage Technology 15 support; Support Intel® Rapid Storage Technology enterprise 5.1 for X-Series(6-core and above) CPU RAID; Intel® Optane™ Memory Ready.
Тип памет:
Intel® Core™ X-series Processors (6-core above); 8 x DIMM
Un-buffered Memory ; * Hyper DIMM support is subject to the physical characteristics of individual CPUs. * Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
I/O:
2 x LAN (RJ45) port(s); 3 x USB 3.1 Gen 2 Type-A; 1 x USB 3.1 Gen 2 USB Type-CTM; 4 x USB 3.1 Gen 1 ; 4 x USB 2.0 (one port can be switched to USB BIOS Flashback) ; 1 x Optical S/PDIF out; 5 x Audio jack(s); 1 x USB BIOS Flashback Button(s); 1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac+ WiGig 802.11ad and Bluetooth v4.1).
Connectors:
1 x Aura Addressable Strip Header(s); 1 x AAFP connector; 1 x Aura RGB Strip Header; 1 x USB 3.1 Gen 1 connector(s) support(s) additional 2 USB 3.1 Gen 1 port(s) ; 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s); 1 x M.2 Socket 3 with M key
type 2242/2260/2280 storage devices support (SATA & PCIE 3.0 x 4 mode); 1 x M.2 Socket 3 with M key
type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4 mode); 7 x SATA 6Gb/s connector(s); 1 x M.2_FAN connector; 1 x VROC_HW_Key; 1 x CPU Fan connector(s) ; 1 x CPU OPT Fan connector(s) ; 2 x Chassis Fan connector(s) ; 1 x W_PUMP+ connector ; 1 x AIO_PUMP connector ; 1 x Thunderbolt header(s); 1 x 24-pin EATX Power connector(s); 1 x 8-pin ATX 12V Power connector(s); 1 x 4-pin ATX 12V Power connector(s); 1 x EZ XMP switch; 1 x System panel(s) (Q-Connector) (Chassis intrusion header is inbuilt); 1 x 5-pin EXT_FAN(Extension Fan) connector; 1 x MemOK! button(s); 1 x Thermal sensor connector(s); 1 x Power-on button(s); 1 x Reset button(s); 1 x Clear
Audio:
Realtek® ALC S1220A 8-Channel High Definition Audio CODEC: - Impedance sense for front and rear headphone outputs; - Internal audio Amplifier to enhance the highest quality sound for headphone and speakers; - Supports : Jack-detection
Multi-streaming
Front Panel Jack-retasking; Audio Feature : - DTS Connect; - DTS Headphone:X ; - Optical S/PDIF out port(s) at back panel; - Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference; - Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals; - Premium Japanese-made audio capacitors: Provide warm
natural and immersive sound with exceptional clarity and fidelity; - Unique de-pop circuit: Reduces start-up popping noise to audio outputs; - EMI protection cover to prevent electrical noise to affect the amplifier quality; Separate layer for left and right track
ensuring both sound deliver equal quality.
LAN:
Intel® I219V
1 x Gigabit LAN Controller(s)
featuring Turbo LAN; Intel® I211-AT
1 x Gigabit LAN
featuring Turbo LAN; Dual Gigabit LAN controllers- 802.3az Energy Efficient Ethernet (EEE) appliance; ASUS Turbo LAN Utility; ASUS LAN Guard.
BIOS:
128 Mb Flash ROM
UEFI AMI BIOS
PnP
DMI3.0
WfM2.0
SM BIOS 3.0
ACPI 6.0
Multi-language BIOS
ASUS EZ Flash 3
CrashFree BIOS 3
F11 EZ Tuning Wizard
F6 Qfan Control
F3 My Favorites
Last Modified log
F12 PrintScreen and ASUS DRAM SPD (Serial Presence Detect) memory information
